RoHS Certified 250*47*25mm Electromagnetic Lock with JS-28L Bracket
Product Details:
| Place of Origin: | China |
| Brand Name: | JUNSON |
| Certification: | CE, FCC, ROHS, Reach |
| Model Number: | JS-280S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | 9-15usd |
| Packaging Details: | 10pcs/carton |
| Delivery Time: | 3-5 days |
| Payment Terms: | 100% prepaid |
| Supply Ability: | stock |
|
Detail Information |
|||
| Holding Force: | 600lbs | Voltage: | DC 12V/24V |
|---|---|---|---|
| Input Mode: | NO/NC/COM | Size: | 250*47*25mm |
| Surface Treatment: | Anodizing | Weight: | 2.5KG |
| Available Bracket: | JS-28ZL, JS-28L, JS-28U | Output Mode: | NO/NC/COM |
| Highlight: | 250*47*25mm electromagnetic lock,rohs certified electromagnetic lock,js-28l electromagnetic lock |
||
Product Description
Product Description of RoHS Certified 250*47*25mm Electromagnetic Lock:
An electromagnetic lock, also known as a magnetic lock or magnetic door lock, is an access control system used to secure doors and gates. It consists of an electromagnet and an armature plate, with an indicator LED. When the current is applied, the electromagnet produces an electromagnetic field, which attracts the armature plate and keeps the door locked. This model has a current of 0.45A, a holding force of 600lbs and is suitable for door thickness from 35-50mm. It offers three output modes: NO, NC and COM.
Features of RoHS Certified 250*47*25mm Electromagnetic Lock:
- Product Name: Electromagnetic Lock
- Output Mode: NO/NC/COM
- Suitable Door Thickness: 35-50mm
- Indication: LED
- Operating Temperature: -20℃~+55℃
- Surface Treatment: Anodizing
Applications of RoHS Certified 250*47*25mm Electromagnetic Lock:
The JUNSON JS-280S electromagnetic lock is an electric smart lock that offers a secure and reliable way to lock your home. It is made in China and certified with the CE, FCC, ROHS, Reach standards, and requires a minimum order quantity of 10. The price ranges from 9 to 15 USD, and it comes with 10 pieces/carton in its packaging. Delivery will take 3 to 5 days, and payment is 100% prepaid. There is an abundance of stock available. The output mode is NO/NC/COM, and it has an LED indication. The weight is 2.5KG, and it is suitable for door thickness between 35 to 50mm, with a size of 250*47*25mm.
Technical Parameters:
| Parameter | Value |
|---|---|
| Voltage | DC 12V/24V |
| Output Mode | NO/NC/COM |
| Material | Aluminium Alloy |
| Indication | LED |
| Certification | CE, FCC, RoHS |
| Current | 0.45A |
| Size | 250*47*25mm |
| Suitable Door Thickness | 35-50mm |
| Operating Temperature | -20℃~+55℃ |
| Holding Force | 600lbs |
| Product Name | Electromagnetic Lock, Electric Smart Lock, Magnetic Lock |
Customization:
- Brand Name: JUNSON
- Model Number: JS-280S
- Place of Origin: China
- Certification: CE, FCC, ROHS, Reach
- Minimum Order Quantity: 10
- Price: 9-15usd
- Packaging Details: 10pcs/carton
- Delivery Time: 3-5 days
- Payment Terms: 100% prepaid
- Supply Ability: stock
- Material: Aluminium Alloy
- Indication: LED
- Voltage: DC 12V/24V
- Holding Force: 600lbs
- Operating Temperature: -20℃~+55℃
JUNSON JS-280S Electromagnetic Lock is a highly reliable electric smart lock, made of aluminum alloy material and ideal for magnetic lock applications. It is CE, FCC, ROHS, REACH certified and features a 600lbs holding force, DC 12V/24V voltage, LED indication, and a temperature range of -20℃~+55℃. You can order 10 pcs per carton and it will be delivered within 3-5 days with 100% prepaid payment terms.
